Description
Technical Specification
| Model | AC-250 | AC-300 | AC-350 | AC-425 | AC-530 | |
| Cutting Capacity Round (mm) | 250 | 300 | 350 | 425 | 530 | |
| Cutting Capacity Square (mm) | 250×250 | 300×300 | 350×350 | 425×425 | 530×530 | |
| Blade Dimension | 3760x27x0.90 | 4100x34x1.10 | 4420x34x1.10 | 4860x41x1.30 | 5800x54x1.30 | |
| Blade Speed | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | |
| Power Required | Saw Drive | 1.50/2.00 | 2.20/3.00 | 3.70/5.00 | 5.50/7.50 | 7.50/10.00 |
| Kw/Hp440 V AC | Hyd. Drive | 0.75/1.00 | 0.75/1.00 | 0.75/1.00 | 1.75/1.00 | 1.75/1.00 |
| 50Hz 3 Phase | Coolant Pump | 0.12/0.16 | 0.12/0.16 | 0.12/0.16 | 0.12/0.16 | 0.12/0.16 |
| Hydraulic Tank | litre | 40 | 50 | 60 | 60 | 80 |
| Coolant Tank | litre | 60 | 60 | 60 | 60 | 80 |
Standard Accessories
- Hydraulic Blade Machine
- Auto Saw Frame Height Adjustment
- Heavy Duty Reduction Gear Box
- Stepless Cutting Feed Regulation
- Complete Electric System & Servo System
- Complete Coolant System
- Driven Chip Brush
- Complete Hydraulic System
- PLC Control for all Electric & Hydraulic Function
- Hydraulic Full Stroke Clamping Vice (with Pressure regulator)
- Carbide & Roller Blade Guide for long life accurate cutting
- Blade Breakage Detector
Optional Accessories
- Chip Conveyer
- A.C Drive for Infinetly Variable Speed Control
- Job Roller Stand
- Bundle Cutting Attachment
- Bi-Metal Bandsaw Blade
- Variable Vice Pressure for thin walled job
- Wire Brush
- Bar Stand
